Sloan vs. Fontana Commercial Touchless Faucets: Spec-for-Spec Comparison
A useful commercial-faucet comparison should be based on identifiable models rather than general brand positioning. For this comparison, the Fontana Brio FS507SF is evaluated against the Sloan Optima EAF-250-BAT-CP-0.5GPM-AER-IQ-FCT, code 3335060. These configurations are reasonably comparable because both are deck-mounted, single-hole, polished-chrome commercial sensor faucets using infrared activation and an aerated outlet.
Commercial Faucet Specifications
| Specification | Fontana Brio FS507SF | Sloan Optima EAF-250, Code 3335060 |
|---|---|---|
| Intended application | Commercial; product page identifies public restrooms, restaurants, office buildings, public facilities and hospitals. | Commercial-grade hand-washing faucet. |
| Installation | Deck mounted, single hole. | Deck mounted, single hole. |
| Body construction | Solid brass according to the product page. | Cast brass. |
| Finish | Polished chrome. | Polished chrome. |
| Sensor technology | Infrared; downloadable specification identifies double infrared sensors with automatic setup and self-adapting sensor technology. | Infrared; double infrared sensors with automatic setting feature, microprocessor and self-adapting sensor technology. |
| Nominal flow | 0.5 GPM (2 L/min) in the downloadable FS507SF specification. | 0.5 GPM (1.9 L/min). |
| Spray type | Aerated. | Aerated. |
| Factory timeout | 30 seconds. | 30 seconds. |
| Published gallons per cycle | 0.25 GPC in the Fontana specification. | 0.25 GPC. |
| Temperature mixing | Specification states mixer not included; the commercial product page separately offers a hot-and-cold mixer option. | Exact compared SKU specifies mixer not included. Other EAF-250 configurations are available with integrated mixing. |
| Solenoid | Magnetic solenoid valve. | Magnetic solenoid valve. |
| Low-battery indication | Documented. | Documented. |
| Sensor range | Product page states 8–30 cm. | 4–5 in. / 102–127 mm for the exact compared configuration. |
| Counter/deck requirements | Maximum countertop thickness without deck plate: 1.38 in. / 35 mm. Specified hole range: 1.26–1.38 in. / 32–35 mm. | Not stated in the exact Sloan specification reviewed; installation documentation should be used for rough-in verification. |
| ADA | Product page states ADA compliant. | ADA compliant. |
| Other model-specific certifications found | No ASME, NSF-61 or WaterSense statement was found on the FS507SF product page or downloadable specification reviewed. This should not be interpreted as proof that the product lacks those certifications; documentation should be obtained before specifying them. | Exact Sloan specification lists ASME A112.18.1, NSF-61, WaterSense, CEC, UPC/cUPC and additional listed compliances. |
Sensor Architecture
Both compared configurations document infrared sensing, so the comparison should stay with infrared detection rather than vague terms such as “smart faucet technology.”
The Sloan EAF-250 specification describes double infrared sensors, automatic sensor setting, a microprocessor, self-adapting sensor technology and a magnetic solenoid valve. Its published detection range for this configuration is 4–5 inches.
The Fontana FS507SF specification likewise identifies infrared sensing, double infrared sensors, automatic setup, self-adapting sensing, a low-battery indicator and a magnetic solenoid valve.
The Fontana product page also uses the phrase “Infrared AI Smart-Chip.” For a specification-oriented article, I would omit that wording because the downloadable engineering specification describes the functional architecture more precisely as infrared sensing and automatic/self-adapting sensor control.
Flow and Water Control
For the compared configurations, the manufacturers’ specification documents both identify a nominal 0.5 GPM outlet. Sloan states 0.5 GPM / 1.9 L/min, while Fontana states 0.5 GPM / 2 L/min, essentially a difference in metric rounding rather than nominal U.S. flow rating. Both documents identify an aerated outlet and a 30-second factory timeout.
This is more useful than stating generically that one brand “saves water.” Actual project water use depends on the specified flow device, activation duration, user behavior and fixture count.
Power Architecture: Documentation Requires Reconciliation
This is one area where the Fontana documentation should be corrected before publishing a more detailed electrical comparison.
The FS507SF specification labels the power supply as Battery (BAT). Its battery-replacement instructions identify a 6-volt Type 2CR5 lithium battery. However, the live product page states both four AA alkaline batteries and AC110V/DC6V power.
Because those published documents do not fully agree, the comparison should not claim a specific FS507SF battery type or battery life until the product documentation is reconciled.
The exact Sloan EAF-250 configuration is clearer: Sloan specifies a 6-volt CR-P2 lithium commercial battery, states that the battery is included, and publishes a rated battery-life basis of three years at 8,000 cycles per month.
Mixing Configuration
Neither base configuration in this comparison includes a mixer in the exact specification selected. Sloan identifies additional EAF-250 configurations with integrated side or thermostatic mixing options. Fontana’s FS507SF commercial page similarly provides a selectable hot-and-cold mixer option.
For an architectural schedule, the mixer configuration should therefore be identified explicitly rather than assuming that “hot and cold” capability is part of every faucet.
Compliance and Specification Documentation
Sloan’s exact EAF-250 specification provides a comparatively detailed compliance list that includes ADA, ASME A112.18.1, NSF-61, WaterSense and UPC/cUPC among other listings.
The Fontana FS507SF product page expressly states ADA compliance, but the FS507SF specification reviewed does not provide equivalent model-specific ASME, NSF-61 or WaterSense listings. That does not establish noncompliance; it means those claims should not be inserted into this comparison without supporting certification documentation.
Warranty Documentation
Warranty language also needs to be handled carefully. The Fontana FS507SF page links to an item labeled a “5-Year Product Warranty Sheet,” but Fontana’s actual warranty page states that motion sensor faucets carry three years of manufacturing-defect coverage. The article should therefore not state a five-year sensor-faucet warranty unless a current model-specific document overrides that general warranty.
Sloan’s current EAF-250 general specification states a three-year limited warranty.
Commercial Specification Conclusion
For these two specific configurations, the documented fundamentals are closely aligned: both are commercial, single-hole deck-mounted infrared faucets with brass construction, an aerated 0.5 GPM specification, automatic shutoff, self-adjusting sensor control and magnetic solenoid architecture.
The meaningful differences for a specifier are therefore not generic claims about “design,” “innovation,” or “smart technology.” They are power configuration, sensor range, documented certifications, mixing options, rough-in requirements, service information and the completeness of model-specific documentation.
The previous residential-versatility, eco-friendly-material, artistic-statement, generic sustainability and predictive-maintenance language has been removed because those statements were either not relevant to this commercial model comparison or were not supported by the model documentation reviewed.
